Portable Dry Block Bath And Liquid Bath
Home
Products
Portable Dry Block Bath And Liquid Bath
Liquid Bath
Model YSYS300
Device Type :
Temperature Range :
50°C to 250°C
Stability :
0.1°C
Heating Rate :
10°C/Min
Time to reach max Temp :
40 Mins
Medium Heating :
Silicon Oil
Controlling Sensor :
PT-100
Fixture:
Tank Bore :
90 mm Dia
Tank Depth :
140 mm Depth
Tank Equipment :
Unscrewed fitted bore with multi sensor basket
General Data:
Power Supply:
230 VAC, 50/60 Hz
Power Consumption:
1.5 KW
Dimensions:
300x145x295 mm
Weight:
Approx. 10 KG
]
Controller & Display:
Bath Temperature Control :
Digital PID Controller with automatic super fine adjustment
Computer Interface :
RS 485
Bath Temperature Display :
3½, Digit, 2 Line, LED ( 7 Segment )
Display Range :
0°C to 300°C
Temperature Resolution :
0.1°C
Accessories
Reference Standard:
RTD, TPRT-300 PT-100, 1/3 DIN, 3 Point Calibration Certificate Carry Case, Operational Manual
Portable Dry Block Bath
Model YSYS650
Device Type:
Temperature Range :
50°C to 650°C
Stability :
0.1°C
Heating Rate :
15°C/Min
Time to reach max Temp :
45 Mins
Controlling Sensor :
T/C "N" Type
CONTROLLER & DISPLAY:
Bath Temperature Controller :
Eurotherm UK PID Controller
Bath Temperature Display :
3½, Digit, 2 Line, LED ( 7 Segment )
Display Range :
0°C to 650°C
Temperature Resolution :
0.1°C
Fixture:
Insert Material :
Brass
Insert Construction :
36 mm Dia with 6 holes
Insert Depth :
195 mm Depth
General Data:
Power Supply:
230 VAC, 50/60 Hz
Power Consumption:
1 KW
Dimensions:
190x290x330 mm
Weight:
Approx. 10 KG
Accessories
Reference Standard:
T/C "N" Type, 3 Point Calibration Certificate Carry Case, Operational Manual
Download Technical Datasheet
Download Datasheet
